Boya BY-PVM3000S XLR Shotgun condenser microphone (Short)

Boya BY-PVM3000S - XLR condenser shotgun microphone (Short)

The Boyan BY-PVM3000 series is a professional microphone system consisting of three different sizes of shotgun microphones: short, medium and long. The longer the microphone, the narrower the area it captures sound.

The microphone's super-hertta directional pattern captures clear sound from only one direction, filtering out unwanted background noise from the audio track. In addition, the microphone has a built-in low-pass filter that can be activated by a switch if required. This filter is very useful in situations where background noise such as air conditioning noise is present, as it eliminates it from the soundtrack.

The BY-PVM3000 has a 3-pin XLR output connector. The microphone can also be connected to a 3.5mm TRS socket using an adapter cable (sold separately).

BY-PVM3000S -model differs from the other models in the series in its shorter length. The S model has a pick-up angle of about 70º, which is more suitable for situations where the sound source is close to the microphone. The PVM3000S therefore picks up the most sound around the microphone of the three different sizes.

Technical specifications

• Transformer: electret
• Directional pattern: superhertta
• Filter: 2-stage low-pass filter
• Low frequency filter switch: 150 Hz
• Signal-to-noise ratio: 80 dB
• Frequency response: 40 20 000 Hz
• Sensitivity: -32 dB
• Output impedance: 50Ω
• Power supply: 24/48 V DC phantom power or 1.5V AA battery
• Net weight: 163 g
